Product Details Introduction

Technical Description of GE 193X643ABG222 Control Board

GE 193X643ABG222 is a functional control board in the General Electric 193X series, commonly used in GE's industrial automation and drive control systems to perform critical control logic, signal processing, and module coordination functions. This board is known for its high reliability and modular design, and is an important component of various GE classic drive systems.

Basic parameters

Model: 193X643ABG222

Name: Control Board

Manufacturer: General Electric (GE)

Series: GE 193X Series

Type: Functional Logic Control Module

Structure type: slot type PCB board, gold finger interface

Power requirement:+5V DC/± 15V DC (from the system main power supply or power module such as 193X643ABG110)

Working temperature range: -20 ° C to+70 ° C

Exterior specifications: Standard 193X series board size

Functional Features

System logic control core: As the main control logic module of the system, it coordinates the execution of various control commands.

Signal processing and transformation: Receive signals from sensors and other control boards, and perform operations such as amplification, filtering, and processing.

Control signal output: Output control logic signals for execution units (such as relays, drive modules, motors).

Modular design: convenient for maintenance, replacement, and system expansion, suitable for various combinations of GE control systems.

Reliability design: using industrial grade electronic components with excellent anti-interference performance, suitable for high temperature, high humidity, and high vibration environments.

Status indication function: Some versions come with LED status indication for debugging and running status monitoring.

Application scenarios

GE Mark II/Mark IV Industrial Drive Control System

Power plant turbine/auxiliary control unit

Industrial Process Automation Control Platform

AC/DC motor control cabinet

Core control board for control cabinets in metallurgy, mining, and petrochemical industries
