193X643ADG114 Static Controller

193X643ADG114 Static Controller

Product Details Introduction

GE 193X643ADG114 is a high-performance Static Regulator/Controller in the General Electric 193X series, mainly used in GE industrial control systems for precise voltage and current regulation and dynamic response control of motors or variable frequency drive systems. This module achieves efficient and mechanical wear free steady-state regulation through static electronic devices such as thyristors, amplifiers, etc.

Basic parameters

Product model: 193X643ADG114

Product Name: Static Regulator/Static Controller

Series: GE 193X Control Board Series

Manufacturer: General Electric (GE)

Power requirement:+5V/± 15V DC (supplied by the system power module such as 193X643ABG)

Installation method: slot installation, backplane connection

Working temperature range: -20 ° C to+70 ° C

Appearance specifications: Standard PCB board with gold finger plug

Functional Features

The core function of a static regulator is to achieve static regulation of voltage, current, and frequency in the system, replacing traditional mechanical regulating components;

Fast response: using semiconductor amplification and control components to achieve millisecond level rapid adjustment;

Strong stability: capable of long-term continuous operation in high-frequency switching control systems, with voltage/current closed-loop regulation function;

Control logic integration: embedded with key logic, operation, and comparison circuits to achieve feedback control closed-loop;

Anti interference design: equipped with input signal filtering, overvoltage protection, and short circuit protection functions;

Indication function: Equipped with status indicator lights (LED) for running status and fault diagnosis (supported in some versions).

Application scenarios

GE power plant automatic control system (such as steam turbine generator set)

Control of High Power DC/AC Motor Drive System

GE Mark II/Mark IV Drive and Excitation System

Speed control system for continuous production lines in metallurgy, papermaking, chemical industry, etc

High voltage frequency converter and voltage stabilization control module in inverters

Product imag
