PACIFIC 6410-009-N-N-N Robot module

Configuring Module Parameters

1 Click on the [+] sign next to the module icon to expand module information.

2 Click on the [+] sign next to any icon to view module information and configuration options.

3 Double-click any icon to open an Edit dialog box.

4 To edit a parameter, select the parameter in the left pane and make your changes in the right pane.

5 Click OK to save your changes.

Printing a Configuration File

1 Select the module icon, and then click the right mouse button to open a shortcut menu.

2 On the shortcut menu, choose VIEW CONFIGURATION. This action opens the View Configuration window.

3 In the View Configuration window, open the FILE menu, and choose PRINT. This action opens the Print dialog box.

4 In the Print dialog box, choose the printer to use from the drop-down list, select printing options, and then click OK.

Downloading the Project to the Module Using a Serial COM port

For the module to use the settings you configured, you must download (copy) the updated Project file from your PC to the module.

1 In the tree view in ProSoft Configuration Builder, click once to select the module.

2 Open the Project menu, and then choose MODULE/DOWNLOAD. The program will scan your PC for a valid com port (this may take a few seconds). When PCB has found a valid COM port, the Download dialog box will open.

3 Choose the COM port to use from the dropdown list, and then click the DOWNLOAD button. The module will perform a platform check to read and load its new settings. When the platform check is complete, the status bar in the Download dialog box will display the message Module Running.

1.Payment method and delivery

Shipment: EMS,DHL,UPS & FEDEX

Payment: T/T or Western Union

2. About us

We are professional company and we are expert in this business, we have highly experienced production team, or sales team, or purchase team, we have most advanced production line. We are reputable in the market.

3. Application industry

Our main products are widely used in metallurgy, oil and gas, glass manufacturing, aluminum, petrochemical, coal mine, paper making and printing, textile printing and dyeing, machinery, electronic manufacturing, automobile manufacturing, tobacco, plastic machinery, electricity, water conservancy, water treatment/environmental protection, municipal engineering, boiler heating, energy, power transmission and distribution, etc.
