The main products

Spare parts spare parts, the DCS control system of PLC system and the robot system spare parts,

Brand advantage: Allen Bradley, BentlyNevada, ABB, Emerson Ovation, Honeywell DCS, Rockwell ICS Triplex, FOXBORO, Schneider PLC, GE Fanuc, Motorola, HIMA, TRICONEX, Prosoft etc. Various kinds of imported industrial parts

IC660ELB921M  Gas turbine electrical card

Quick Access Use the Quick Access mode when the ID of the Target Table record to be loaded is known. Use the numeric keypad to enter the ID and then press the Target Memory softkey to load the record. If the record is available, the data is loaded. If the record is not found, an “ID not found” error displays and the currently loaded target is retained. List Selection Use the List Selection mode when the ID of the Target Table record is unknown. To use the List Selection mode: 1. Press the Target Memory softkey without any preceding data entry. The Target Search screen displays. 2. Enter any search restrictions required or leave selections as they are to retrieve all records. 3. Press the SEARCH softkey to view the selected records in the table. 4. Use the UP and DOWN navigation keys to scroll through the list until the desired record is highlighted. 5. Press the OK softkey to load the selected record from the list and return to the weighing operation screen, or Press the EXIT softkey to return without loading the record. SmartTrac is a graphical display visualization of either the displayed weight or gross weight as selected in Setup. The visualization may be a bar graph, cross hairs, or an over/under display. The following conditions allow SmartTrac to display: • A Target must be defined and selected. • A SmartTrac size other than none must be selected at Setup > Terminal > Display. • A SmartTrac graphic display type must be selected for the scale at Setup > Application > Operation > Target > Scale #. Refer to the IND780 Technical Manual, Chapter 3.0, Configuration, for details about these settings.

Display Sizes

HFigure 2-19 shows a small size SmartTrac bar graph. HFigure 2-20 shows an over/under display in medium size and Figure 2-21 a cross hairs display in large H size. Note the effect on the main weight display area. In each of these examples, the display shows the weight on target. The small bar graph does not include target weight, description and tolerance information; with a medium or large bar graph, the target description appears above the bar and target and tolerance below it (see Figure 2-22).

Display Colors Note that the examples shown below are from a monochrome display. In IND780s with a color display, the following conventions are used: • Red—Over tolerance • Green—Within tolerance • Blue—Under tolerance In cross hairs mode, the colors listed above are used as background fill. In this case, the cross hairs appear in white when within tolerance (see Figure 2-21), H and yellow when over or under tolerance. Bar Graph Mode The operator adds material until the measured value is within an acceptable tolerance limit. Normally an operator will add material quickly when the container is not nearly full and more slowly as the target value approaches. Figure 2-22 H shows a SmartTrac bar graph with a displayed value below the lower tolerance lim
