ABB PFSK141 3BSE006513R1 Control card

Group display (Fig.2.16) The group display can be used to show either – normalized representations of up to 56 loops by summarizing the operating states or – free representations (Fig.2.15) using simple symbols, alphanumeric characters of digital displays or – a combination of normalized and free representations. The working field on the screen is subdivised into a grid of 56 location numbers:The process–related group name specified in the GP block and the block name are automatically shown in the group display. A group display is selected by entering the group display number via the process communication keyboard. The following process communication keyboard keys must be depressed to select group display 13 (GP 13)

Area display

The area display gives a normalized representation of up to 56 groups or free representations or a combination of normalized and free representations using colored – symbols – alphanumeric characters – digital displays. The work area on the screen is subdivised into a grid with 56 location numbers (Fig,2.18). The area display is selected via the process communication keyboard. The following keys must be depressed to select the area display.

Operator Input and Monitoring for Configuration Tasks

the function blocks in interactive operation. During configuration, three different display types can appear in the work area of the VDU: Block list (Fig. 2.19) consisting of inputs and outputs and the associated – Parameters – Interconnection data – Operating values – Attributes. The variable values are normally updated every two seconds (can be selected via GA.ORPA) Processing sequence (Fig. 2.20) The processing sequence consists of the names of the blocks installed in the sequence, including their process–related names.XB blocks, which control the processing sequence, also display the closing status and the cycle time multiplication. The system displays the processing sequence that is related to the default processing level (ZYK).
