The main products

Spare parts spare parts, the DCS control system of PLC system and the robot system spare parts,

Brand advantage: Allen Bradley, BentlyNevada, ABB, Emerson Ovation, Honeywell DCS, Rockwell ICS Triplex, FOXBORO, Schneider PLC, GE Fanuc, Motorola, HIMA, TRICONEX, Prosoft etc. Various kinds of imported industrial parts

07BR61R1 GJV3074376R1 Channel module

Z Enter the relay slave address and COM port values (from the S1 PQMII SETUP ÖØ FRONT PANEL RS232 SERIAL PORT setpoints menu) in the Slave Address and COM Port fields. Z Enter the physical communications parameters (baud rate and parity settings) in their respective fields. Z Click the Read Order Code button to connect to the PQMII device and upload the order code. If a communications error occurs, ensure that the PQMII serial communications values entered in the previous step correspond to the relay setting values. Z Click OK when the relay order code has been received. The new device will be added to the Site List window (or Online window) located in the top left corner of the main EnerVista PQMII Setup Software window. The PQMII Site Device has now been configured for serial communications To upgrade the PQMII firmware, follow the procedures listed in this section. Upon successful completion of this procedure, the PQMII will have new firmware installed with the original setpoints.

Saving Setpoints to a File

Before upgrading firmware, it is important to save the current PQMII settings to a file on your PC. After the firmware has been upgraded, it will be necessary to load this file back into the PQMII. Z To save setpoints to a file, select the File > Read Device Settings menu item. The EnerVista PQMII Setup Software will read the device settings and prompt the user to save the setpoints file. Z Select an appropriate name and location for the setpoint file. Z Click OK. The saved file will be added to the “Files” pane of the EnerVista PQMII Setup Software main window. 4.3.3 Loading New Firmware Z Select the Commands > Upgrade Firmware menu item. A warning will appear. Z Select Yes to proceed or No the abort the process. Do not proceed unless you have saved the current setpoints as shown in the previous sectionThe EnerVista PQMII Setup Software now prepares the PQMII to receive the new firmware file. The PQMII will display a message indicating that it is in Upload Mode. While the file is being loaded into the PQMII, a status box appears showing how much of the new firmware file has been transferred and how much is remaining. The entire transfer process takes approximately five minutes.
