GE DS200UPSAG1AEC Embedded controller

The Digital Output bussed 24VDC (DO24V) module provides reliable 24V digital output signals to control other process equipment as well as solenoid valves and interposing relays. The DO24V can support high energy outputs to reduce the number of external components in the output loop. Notable Features

• Extensive internal diagnostics to ensure data integrity

• Optional redundancy

• Direct/Reverse output support

• Safe-state (FAILOPT) behaviors

• “Fuse-less” short circuit protection

• Latched, pulsed or pulse-width modulated output (per channel)

• Galvanic isolation

Bussed 24VDC DO

 The Digital Output Bussed 24VDC has provisions for both internal and external field power excitation. As a bussed output device, all of the outputs share a common return (ground). All outputs get their power from the same source, which can be either the system power supply or an externally connected 24V power supply. When selection is from an external source, outputs can be galvanically isolated from the Series C power system. Fuse-less Short Circuit Protection This unique feature allows a short circuit to exist without blowing any fuses. When a particular channel is shorted, internal circuits detect this and remove power to the field connection. The channel remains de-energized until the short circuit is repaired. FAILOPT Series C DO module will support FAILOPT parameter on a per channel basis. The output can be directed by configuration to either HOLD THE LAST VALUE, or SHED to a SAFE VALUE. The safe value can be configured by the user.

Digital Output – Relay IOTA

The Digital Output Relay provides a dry contact for isolated low voltage / low current or high voltage / high current discrete output applications. Each relay supports a Form-A or Form-B output based on jumper configuration. The Relay IOTA uses the Digital Output 24V (DO24V) IOM with a special IOTA to support the Relay IOTA. All characteristics of the DO24V IOM are incorporated here. Notable Features • Galvanic isolation • Socketed relays • Isolated Dry Contact • Jumper selection between NO and NC contacts • Counter EMF Snubbing Circuit • LED indication for each channel ON condition
