GE DS200TCCBG3B Measuring unit

Scope of delivery

 Setup package to install the technology package "UserLogonUSB" on the robot controller

 Windows Software "UserLogonUSB Dongle Manager" to configure the dongle on the PC

 USB dongle with stored customer password

 Individual customer password for dongle configuration

 Customer Config-file to activate the option "block foreign dongle

Installation / removal to / from the robot controller The installation/uninstallation is done via the additional software option. These can be found in the main menu under start-up. 3.1.1 System requirements for running Minimum Hardware Requirements  Installation on KRC4: KUKA System Software 8.2  Installation on KRC2: KUKA System Software >=5.5  USB 2.0

Install UserLogonUSB or upgrade to new version on KRC4

Extract the .Zip file 2. Copy the installation folder OrangeApps.UserLogonUSB containing the setup files to a USB stick or directly to a drive on the target system (for example, d: \). 3. When installing from a USB stick, connect this to the controlling PC or the SmartPad. 4. Choose commissioning Additional software from the main menu. 5. Click the button New software. 6. You’ll get a list of available software for installation. If there’s no entry OrangeApps.UserLogonUSB in the list, click Refresh. If now the entry appears, go to step 9. 7. If the entry does not appear, the drive from where to install must be configured first. To do this, choose Configuration. In the new window you now have the option to select the path where to find the folder OrangeApps.UserLogonUSB.

Select an empty cell in the installation paths

for options and click path selection. The available drives are displayed. Select the drive on which the folder OrangeApps.UserLogonUSB is located and save your selection with. The window closes. OrangeApps.UserLogonUSB should now appear as an entry in the list. If this is not the case, press refresh and/or repeat steps 7 to 8 9. Highlight the entry OrangeApps.UserLogonUSB and press Install. Confirm the security prompt with Yes. 10. Read the license agreement carefully. Explain your agreement to the license terms by clicking I Accept and continue the installation by clicking Continue. If you do not agree with the license terms, please cancel the installation by clicking Cancel. 11. The installation will be prepared now. To perform the final installation the control PC has to be restarted. This can immediately be executed by clicking Reboot Control PC now or later by clicking later. 12. If you select later, the window is closed. In order finalize the installation proceed with step 14. If you select Reboot Control PC now, a restart of the control PC will be performed. Step 14 is then executed.

 Company product range

----------------------Ruichang Mingsheng Automation Equipment Co., Ltd----------------------

PLC module, programmable controller, CPU module, IO module, DO module, AI module, DI module

Network communication module,

Ethernet module, motion control module, analog input module, analog output module, digital input module, digital output

Module, redundancy module, power module, relay output module, relay input module, processor module
