GE DS200TBQCG1B Gas turbine acquisition card

Motor turns in reverse direction Speed reference signal pins 9 and 10 reversed Reverse pins 9 and 10. Motor connections pins reversed Reverse pins 17 and 18. Tachogenerator connection pins reversed Reverse pins 11 and 12. 6.3.5 Tacho loss protection when operating in armature feedback Switch 3 set at ON Set switch 3 at OFF.If the tachogenerator feedback mode has been selected, the resistors RAI and RKW must be disconnected. RS resistor selected to improve STOP condition When a RS resistor is fitted, the dynamic response is modified. If this resistor is not required, disconnect it

Asymmetric torque generation

Drive is affected by signal noise When output pins 6 and 7 (voltage reference outputs) are connected with long cables, it may be necessary to install 0.1mF capacitors as follows: Between pin 6 and pin 8 Between pin 7 and pin 8 If the drive is relatively old, it is possible that the following alternative daughter boards may be fitted.Enables speed control with tachogenerator feedback. When used in this position remove RAI resistor.Disables speed control with tachogenerator feedback.

Ethernet Interface Module

 The Ethernet Interface module (IC693CMM321) provides an interface that allows you to attach the Series 90-30 PLC to an Ethernet LAN via an external transceiver and AAUI cable, and to communicate with hosts and other control devices on the network. The Ethernet Interface for the Series 90-30 PLC has client/server capability. As a client it can initiate communications with other PLCs containing Ethernet Interfaces. This is done from the ladder program using the COMMREQ Function Block. As a server it responds only to requests from other devices such as a Host computer running a Host Communications Toolkit application or another Series 90-30 PLC acting as a client.
