GE DS200LRPAG1A Contact DC module

Motor Encoder Error: Quadrant Error Description: An encoder signal error was found during the encoder evaluation. Cause: 1. Defective encoder cable 2. Insulation disturbance on the encoder or the encoder cable 3. Defective drive controller Remedy: For 1. Check the encoder cable and change if necessary. For 2. Use only insulated motor cable and power cables Separate encoder cable from power cables For 3. Exchange drive controller

Low Battery Voltage Cause

 The connected motor has an absolute encoder. The absolute position information is stored in the motor feedback. This memory has a battery powered backup for the electronic circuit. The battery is designed for a operating life of 10 years. If the battery voltage drops below 2.8 V, this message appears. The absolute encoder function is preserved for about 2 weeks. Instructions for Exchanging Batteries Have the following tools and accessories ready: • Torx screwdriver, size 10 • Needle nose pliers, torque wrench • New packaged battery (Part No.: 257101) If the control voltage of the installed battery is turned off, the absolute position is lost. The absolute position must be re-established through the process of the command Set Absolute Measurement.

External Short at Status Outputs

 Description: Status outputs are monitored for short circuits and thermal overload. • If output current exceeds 350mA for about 1µs, then this is acknowledged as a short circuit and the pertinent channel is shut off. The output remains off unti the error is cleared. • With thermal overload, the error is set and the output(s) shut off. After the driver has cooled off, the outputs are switched back on and so on. The error, however, remains until it is cleared. Thermal overload can occur if several outputs are overloaded in excess of 80 mA. Note: Light bulbs, for example, cannot be controlled as their inrush current causes a short-circuit.

Common problem

We have this product in stock, and we can deliver it to you at any time when you need it badly.

*The warranty period of all products is 1 year, which has passed the professional test certification.

*If you need to order more than one product, please contact us, and we can offer you a discount.

*We only use HDL  UPS  and other express delivery methods to deliver spare parts.

*If you find that other suppliers offer lower prices for the same products, we are also willing to offer you further discounts based on their prices.

If you have any other questions, please feel free to contact us via email.

*Please let us know if you need any spare parts, we can give you further assistance, and we are waiting for your inquiry.
