GE DS200DKLBG1ABB Pulse accumulator

In fact of this use no automatic screwdriver (e.g. electronical, pneumatic or hydraulic screwdriver). Use cables for this motors which are equivalent with Rexroth cables. Mount the cables as follows: 1. Dismount the connector-box cover (1), by untwining the screws(7). 2. Dismount the components (2 -5), by untwining the screws (6). 3. Remove protection paper (A). 4. Pull off the inserted connectors X1 and X2 from the motor connection plate.5. Bring on the parts (2 – 5) round the cable. 6. Lead the cable-endings through the opening of the connection box (see Fig. 15-2) and turn on the screws loose(6) of the cable bushing.

Entrance of power and conductor cables

7. Pull back the cable until the shrinking sleeve penetrates the inside of the connection box by about 16mm (see Fig. 15-3). 8. Tighten screws (6) with 2,5 Nm. 9. Tighten up grounding ring terminals (8) and (9) with 1.3 Nm to connector box lid (1). 10. Insert connectors X1, X2 and the encoder connector X3 into appropriate position on the motor panel. 11. Tighten screws in the terminal X1 with 0.5 Nm. 12. Place the connector box into output direction. 13. Make sure that no cable cores are squezed or damaged and tighten the connector box into place with 2.5 Nm.

Adjust the output direction

The connector box lid can be turned 180° when it is mounted. This means the output direction can be set to: • side A or • side B. Note: The cable output direction is side B at the time of delivery. The cable output direction can be selected when mounting power and encoder cable

When fitting the INS0681 power connector with thread, proceed as follows: 1. Put the power connector onto the thread of the connection housing in the correct position. 2. Tighten the union nut of the power connector manually. By leading the cable in further, the power connector can be steadily put to its final position. 3. Tighten the union nut as securely as you can manually.

Common problem

We have this product in stock, and we can deliver it to you at any time when you need it badly.

*The warranty period of all products is 1 year, which has passed the professional test certification.

*If you need to order more than one product, please contact us, and we can offer you a discount.

*We only use HDL  UPS  and other express delivery methods to deliver spare parts.

*If you find that other suppliers offer lower prices for the same products, we are also willing to offer you further discounts based on their prices.

If you have any other questions, please feel free to contact us via email.

*Please let us know if you need any spare parts, we can give you further assistance, and we are waiting for your inquiry.
