GE IS200BICLH1A Thermocouple output card

To change the battery you must work when machine is under load.

 Therefore:

⇒ Any work required on the electric system may only be carried out by skilled electricians.

⇒ Switch off power supply at the drive control systems and save against re-start!

⇒ Switch off power supply at the drive control systems and save against re-start!

 ⇒ Change battery on drive control systems only when control voltage is inserted. Is the control voltage switched off when the battery is removed, the absolute value is lost and when the machine will be switched on, a failing movement could be possible.

Assemble the battery

1. Assembled battery for motor type (Ord. No. No.: R911277133 or: R911281394) and screw terminal (3) with screws (4) tighten (accelerating torque max. 1.0 Nm). Note: Do not squeeze the battery cable! 2. Take on the connector of the battery (2). 3. Close housing lid. 4. Tighten screw (1) with torque spanner

2. 1. Loosen housing screws (1) with a torx-screw driver (appropriate size see Fig. 16-2). 2. Dismount housing lid. 3. Take off the connector of the battery (2). 4. Lossen screws (3) of the battery`s screw terminal and remove the battery.

Selecting Power Cables

 The tables and diagrams shown on the following pages are intended to support you in selecting the power cables required. The example below explains how to proceed. A power cable set, 5.0 m in length, is needed for a MKD112A-024 motor, Natural 60K operating mode, and an HDS02. drive controller. Proceed as follows: 1. Select the motor and the operating mode in the cable selection table. 2. “X” identifies the connection cross-section required. 3. Read the size of the power connector and the connection crosssection from the table header. 4. On the following pages, select the corresponding selection diagram by connector size and connection cross-section. 5. Select the required power cable set in the diagram. Complete the selected ordering type IKGxxxx/xxx.x by the desired length. In the example above, the ordering type IKG4055/xxx.x is taken from the selection diagram. For ordering, complete the ordering type by the desired length.
