REXROTH DKC02.3-040-7-FW Servo drive

Detection of the actuation of the operating elements shown on the display.

 Resistive touch: These devices are operated by touching the operating elements with your finger or with a stylus.

 Infra-red touch: These devices are operated by interrupting the infra-red light matrix with your finger or a suitable object (min. ø 7 mm). It is not necessary to touch the infra-red touch protective panel. B Display Display operating and indication elements.

 Dark during boot up.

 Lit when the touch sensor is ready.

 Flashes when actuating the touch sensor

TOUCH ERROR (red)

 Lit during boot up.

 Dark when the touch sensor is ready.

 Lit in the event of errors.

 Flashes if the infra-red frame is contaminated and has to be cleaned (cleaning the infra-red touch,

 Chapter 7.2.3,  49).

 Flashes if the resistive touch is incorrectly calibrated (touch calibration,

 Document «MN05010007Z-EN System Description Windows CE»

Engineering conditions of acceptability by Underwriters Labaratories Inc. (UL)

 The device must be installed in an end-product. For the approval in accordance with the standard UL 60950, consideration must be given to the following:  The environment of the device must comply with pollution degree 2.  The device must be supplied via a SELV source.  The device must be connected to the protective earth of the end-product (the functional earthing connection of the power supply interface must be connected).  In order to protect the device from potential internet threats, it should be connected to Ethernet networks that are isolated from the internet or safety protected and isolated from the Corporate/Enterprise network by a firewall or router.  Fire protection and electrical protection must be ensured via the end-product (not required for the front of the device)

Application industry

The products can be used in the following industries: power plant, paper making, steel, mining, rubber, water supply, cement, chemical industry, glass, printing Textile, machinery, plastics, coatings, medicine, hospitals, food, hotels, scientific research institutions
