REXROTH 2263117 Analog quantity sequence module

IndustryPack Modules Up to four IndustryPack (IP) modules may be installed on the MVME162. The interface between the IPs and MVME162 is the IndustryPack Interface Controller (IPIC) ASIC. Access to the IPs is provided by four 3M connectors located behind the MVME162 front panel. Optional SCSI Interface An NCR 53C710 coprocessor provides the SCSI interface for the MVME162. Optional LAN Ethernet Transceiver Interface An Intel 82596CA controller provides the LAN Ethernet transceiver interface for the MVME162. Required Equipment The following equipment is required to complete an MVME162 system:

❏ System console terminal

❏ Disk drives and controllers

❏ Operating system

MVME162Bug Firmware

The 162Bug package, MVME162BUG, is a powerful evaluation and debugging tool for systems built around the MVME162 CISC-based microcomputers. Facilities are available for loading and executing user programs under complete operator control for system evaluation. 162Bug includes commands for display and modification of memory, breakpoint and tracing capabilities, a powerful assembler/disassembler useful for patching programs, and a self test at power-up feature which verifies the integrity of the system. Various 162Bug routines that handle I/O, data conversion, and string functions are available to user programs through the TRAP #15 system calls. Note MVME162Bug occupies the first half (512KB) of Flash memory

MVME712 Series Transition Modules

 The MVME712 series transition modules provide an interface between the MVME162 and peripheral devices such as EIA-232-D serial devices, SCSI devices, and LAN Ethernet devices. A P2 Adapter Board or LCP2 Adapter Board and cable are required. Caution Connect peripheral devices to MVME712 serial ports 2 and 4 only. (Serial port 2 is the terminal or bug interface.) Do not connect peripheral devices to serial ports 1 and 3, or to the printer port. An I/O device may be connected to serial port 1 (or 2) on the MVME162 or to serial port 2 (or 4) on the MVME712, but not to both ports. (That is, if an I/O device is connected to MVME162 port 1, no other I/O device should be connected to MVME712 port 2; they are functionally the same port.)
