n GENERAL The FIO (Fieldnetwork I/O) System is connected to the Field Control Unit (FCU) via an ESB, optical ESB, or ER bus. The Field Control Unit (AFV30/AFV40) is connected to an ESB Bus Node Unit (ANB10) or an Optical ESB Bus Node Unit (ANB11). The Field Control Unit (AFV10) is connected to an ESB Bus Node Unit (ANB10) or an ER Bus Node Unit (ANR10). A node unit consists of a power supply module, a bus interface module, and input/output modules that are installed in a base unit. The power supply module, bus interface module, and input/output modules can be configured redundantly. The Unit for Optical ESB Bus Repeater Module (ANT10U) can be used to connect the optical ESB bus in a chain or star configuration. The following shows a system configuration example.When a ER Bus Node Unit is used under the temperature environment (-20 to 0 °C), it requires 10 minutes to start up EB501 after turning on the power switch. When the following modules are installed in ESB Bus Node Unit, Optical ESB Bus Node Unit or ER Bus Node Unit, the ambient temperature should be 0 to 50 °C. AAP149, AAP849, ADV157, ADV557, ADV161, ADV561, ADV859, ADV159, ADV559, ADV869, ADV169, ADV569, ALR111, ALR121, ALE111, ALF111, ALP111, ALP121 When AAI543-6, -F (fast response) is installed in ESB Bus Node Unit, Optical ESB Bus Node Unit or ER Bus Node Unit, the ambient temperature should be 0 to 60 °C.

ESB bus/Optical ESB bus

When using Field Control Unit (AFV30/AFV40) Application An ESB bus or an optical ESB bus is an input/output communication bus that connects the ESB bus node unit or optical ESB bus node unit to the intelligent part of the FCS. Communication Specifications Connectable Units: ESB Bus Node Unit (ANB10), Optical ESB Bus Node Unit (ANB11), and Unit for Optical ESB Bus Repeater Module (ANT10U) Number of Connectable Units: The number of ESB bus node units and optical ESB bus node units that can be connected to the ESB bus varies depending on the selected database. Units for Optical ESB Bus Repeater Module (ANT10U) are not included in the number of connectable units.

: ESB Bus Node Unit (ANB10), Optical ESB Bus Node Unit (ANB11) *2: To connect the ESB bus node unit and optical ESB bus node unit to the FCU (AFV30/AFV40), install the ESB Bus Coupler Module (EC401 or EC402) in slots 7 and 8. EC401 can be connected a maximum of nine Node Units (ANB10or ANB11). EC402 can be connected a maximum of nine Node Units (ANB10or ANB11) on the upper and lower sides, respectively. The sum of the total number of Node Units (ANB10 or ANB11) per FCU should not exceed the specified number. *3: The maximum number of ESB bus node units, optical ESB bus node units, and units for optical ESB bus repeater module that can be installed in a single cabinet is 11 for AFV40.
