The main products

Spare parts spare parts, the DCS control system of PLC system and the robot system spare parts,

Brand advantage: Allen Bradley, BentlyNevada, ABB, Emerson Ovation, Honeywell DCS, Rockwell ICS Triplex, FOXBORO, Schneider PLC, GE Fanuc, Motorola, HIMA, TRICONEX, Prosoft etc. Various kinds of imported industrial parts

PPC902AE101 3BHE010751R0101 Control processor

This appendix describes some technical details of the lower layers implementing the AF 100 communication. The information presented is by no means necessary to install and maintain a Advant Fieldbus 100 network. It merely completes the technical description and is intended for the curious reader only In the document the AF 100 units are generally named without suffix Vx or A unless it is necessary for the functionally described. CI810 is the general term for CI810/CI810V1/CI810V2/CI810A. For example, if media redundancy is described, the description states for a S800 Field Communication Interface (FCI) that the unit to use is CM810V1/CM810V2/CI810A or CM810V1, implicitly including CM810V2/CI810A. In case of uncertainty consult Table 1-3. 1.5 Related Documentation Advant Controller 70, Advant Controller 110, Advant Controller 400 Series, and S800 I/O documentation. 1.6 Release History R0001 was the first release MasterPiece 90 / MasterBus 90 R0101 New name and layout. Advant Fieldbus 100 User’s Guide. R0201 completed with info about S800 I/O. R0301 completed with info about TC514, TC515, and CI627. R0401 includes information about interfaces for full redundant media communication. R0501 includes information about communication interface redundancy with CI522 bus coupler module and modem TC516 for twisted pair media. R0601 redundant FCI for S800 I/O included. R0701 includes information about the possibility to use AF 100 over distances greater than 2000 meters (6,500 ft.) in CI522, CI810 and CI820.

Terminology

 AC An abbreviation of Advant Controller (used in figures and tables). AF 100 An abbreviation of Advant Fieldbus 100 (used in figures and tables). Advant Controller Advant Controller refers to Advant Controller 70, Advant Controller 110 and Advant Controller 400 Series (Advant Controller 410, Advant Controller 450, and Advant Controller 460). AdvaSoft for Windows Personal Computer based operator station with software package AdvaSoft for Windows that can be used on the Advant Fieldbus 100.Communication Interface A communication interface is a device that can communicate on the Advant Fieldbus 100 communication link. Communication Link A communication link is the hardware (for example cables, modems) and the low layers of the protocol that enables the communication interfaces (stations) to exchange data. A communication link can not be redundant on Advant Fieldbus 100. DAT Data base element representing an INTEGER, INTEGER LONG or REAL value or 32 BOOLEAN values. The DAT also contains a VALID flag and a NAME string. DataSet (DS) Data base representation of a block of data to be transmitted. In MasterPiece 90 and Advant Controller 110, the DataSet is used for transmission on MasterBus 90 or Advant Fieldbus 100. DataSet in MasterPiece 200 and in Advant Controller 400 Series is used for transmission on MasterBus 300. DataSet Peripheral (DSP) A data set function for communication on Advant Fieldbus 100. In the controller the DataSet Peripheral is represented with a data base element. Drop Cable The cable from a communication interface or coaxial modem to the coaxial bus cable. EventSet Time tagged events that are sent from an Advant Controller 70, Advant Controller 110 to an Advant Controller 400 Series and AdvaSoft for Windows.
