The main products

Spare parts spare parts, the DCS control system of PLC system and the robot system spare parts,

Brand advantage: Allen Bradley, BentlyNevada, ABB, Emerson Ovation, Honeywell DCS, Rockwell ICS Triplex, FOXBORO, Schneider PLC, GE Fanuc, Motorola, HIMA, TRICONEX, Prosoft etc. Various kinds of imported industrial parts

216DB61 HESG324063R100/J Excitation system card

The bus cables are mounted using Twisted Pair connectors which are inserted into bus connectors on the CI627 communication interfaces (as shown in Figure 2-4 and Figure 2-5). This method of connection enables exchanging a faulty CI627 communication interface without interrupting the communication in the network. NOTE Redundant cables are used to increase availability only, it does not enhance the communication bandwidth.Advant Controller 400 Series is connected with the Advant Fieldbus 100 using the communication interface CI520 which is mounted in a submodule carrier module in Advant Controller 450 and in the CPU in an Advant Controller 410. CI520 must always have an external modem, either a TC625 for coaxial media or a TC512/TC516 for twisted pair. The cable between CI520 and the external modem to use are TK515 (AC 450/AC460) or TK593 (AC 410) (see Figure 1-1 and Figure 2-6).

CI5222 Communication Interface

 Advant Controller 400 Series is connected to Advant Fieldbus 100 using the communication interface CI522, which is mounted in a submodule carrier. Two CI522 modules can form a redundant pair. Communication interface redundancy is achieved by using two CI522s connected to a media redundant bus. Communication interface redundancy is available for Advant Controller 450 only. CI522 is mounted in a submodule carrier module in Advant Controller 450. CI522 must always have external modems, TC516, for twisted pair. TC625 (4 items) or TC512 (4 items). The cables between CI522 and the external modems to use are TK803V018 (AC 450/AC 460) or TK80V036 (AC 410) (see Figure 2-7).Using AdvaSoft for Windows, the Personal Computer is connected to the Advant Fieldbus 100 via cable TK549 to the communication interface CI526, which is inserted in an ISA slot. CI526 must always have an external modem, either a TC625 for coaxial media or TC512/TC516 for twisted pair.The CI8102 Fieldbus Communications Interface (FCI) is an intelligent communication interface between an Advant Controller via the Advant Fieldbus 100 and the S800 I/O modules via the Modulebus. The termination board is a unit where most of the connections to the outside takes place. It is grounded to the DIN-rail through a metallic spring connector. The board carries screw terminals
