FOXBORO FBM213 P0914XL Axial displacement module

❏ MC68040 Microprocessor

❏ 4/8/16/32/64MB of 32-bit DRAM with parity protection or 4/8/16/32/64/128/256MB of 32-bit DRAM with ECC protection

❏ Four 44-pin PLCC ROM sockets (organized as two banks of 32 bits)

❏ 128KB Static RAM (with optional battery backup as a factory build special request)

❏ Status LEDs for FAIL, STAT, RUN, SCON, LAN, +12V (LAN power), SCSI, and VME.

❏ 8K by 8 static RAM and time-of-day clock with battery backup

❏ RESET and ABORT switches

❏ Four 32-bit tick timers for periodic interrupts

❏ Watchdog timer ❏ Eight software interrupts

❏ VMEbus interface

– VMEbus system controller functions

– VMEbus interface to local bus (A24/A32, D8/D16/D32 and D8/D16/D32/D64BLT) (BLT = Block Transfer)

– Local bus to VMEbus interface (A16/A24/A32, D8/D16/D32)

 – VMEbus interrupter – VMEbus interrupt handler

– Global CSR for interprocessor communications

 – DMA for fast local memory

- VMEbus transfers (A16/A24/A32, D16/D32 and D16/D32/D64BLT)

Conformance to Requirements

These boards are designed to conform to the requirements of the following specifications:

❏ VMEBus Specification (IEEE 1014-87)

❏ EIA-232-D Serial Interface Specification, EIA ❏ SCSI Specification

The MVME167 has two 96-position DIN connectors: P1 and P2.

❏ P1 rows A, B, C, and P2 row B provide the VMEbus interconnection.

❏ P2 rows A and C provide the connection to the SCSI bus, serial ports, Ethernet, and printer.
