FOXBORO FBM214d P0914WP Differential expansion module

If your MVME167 is equipped with SRAM battery backup; when the main board power fails, the DS1210S selects the battery as the power source. Each time the board is powered, the DS1210S checks the power source, allowing software to provide an early warning to avoid data loss: ❏ If the voltage of the backup source is less than two volts, the second memory access cycle is blocked. ❏ Because the DS1210S may block the second access, the software should do at least two accesses before relying on the data. With the optional battery backup, the MVME167 provides jumpers (on Optional SRAM Backup Power Source Select Header J8 on page 3-12) that allow the power source of the DS1210S to be connected to the VMEbus +5 V STDBY pin or to the onboard battery.

Lithium batteries

 incorporate inflammable materials such as lithium and organic solvents. If lithium batteries are mistreated or handled incorrectly, they may burst open and ignite, possibly resulting in injury and/or fire. When dealing with lithium batteries, carefully follow the precautions listed below in order to prevent accidents.

❏ Do not short circuit. ❏ Do not disassemble, deform, or apply excessive pressure.

❏ Do not heat or incinerate.

 ❏ Do not apply solder directly.

❏ Do not use different models.

❏ Do not charge.

❏ Always check proper polarity. To remove the battery from the module, carefully pull the battery from the socket. (Data will be lost if a new battery is not installed within 30 seconds.) Before installing a new battery, ensure that the battery pins are clean. Note the battery polarity and press the battery into the socket.

product application

Products are widely used in metallurgy, petroleum, glass, aluminum manufacturing, petrochemical industry, coal mine, papermaking, printing, textile printing and dyeing, mechanical, electronic manufacturing, automobile manufacturing, plastic machinery, electric power, water conservancy, water treatment/environmental protection, boiler heating, energy, power transmission and distribution and so on

Superior products

--ABB Accuray

--ABB Advant OCS

--ABB Advant-800xA

--ABB H&B Contrans T

--ABB H&B Freelance 2000

--Allen Bradley PLC

--GE Ran card machine accessories,PLC

--ICS Triplex Rockwell T8151B/T8461/T8310

--Triconex/Foxboro:3625/3721/3503E/FBM237/FBM242

--Emerson:CE3008/VE3008/SE3008/A6120/A6312

--Motorola:MCP750/MVME162/MVME2604/MVME5100

--Woodward:9907-164/9907-167/9905-144/9905-018

The company is mainly engaged in above brands. You are welcome to inquire from me via email!
