TB852 3BSC950263R1 Terminal module

The status information of the communication interface, CI810, is available with the DB element S800 I/O Station. The status of the CI810 is given by the DIAG terminal in the S800 I/O Station DB element. The following status information is given on the DIAG terminal: ACT CI810 is operating. IDF Identity failure. SE Severe Error: Severe errors in the station. HWE Station Hardware Error. An error in CI810 Hardware. SWE Station Software Error. Restart of the CI810 should probably clear the error. PHE Peripheral Hardware error. Hardware error or missing hardware. PRE Process Errors. ‘Soft’ error condition, for example, I/O channel out of range. CRA Cable Redundancy Available. Indicates that the CI810 is configured to have redundant bus cables. SNA Station Not Available RC1 Redundant cable 1 Failed. Indicates that the communication over the cable #1 of the redundant cable pair does not work. RC2 Redundant cable 2 Failed. Indicates that the communication over the cable #2 of the redundant cable pair does not work. CD Change Diagnostics. RPA Redundant Power A failure. RPB Redundant Power B failure. GE General (unspecified) error. GW General (unspecified) warning. The SE, SNA, IDE, SWE, and GE gives error on the S800 I/O station DB element, inactive ACT (NOT ACT) and the rest except CD and CRA gives warning

DataSet Peripheral Communication

For transmission of data between different nodes DataSet Peripheral (DSP) is used. The maximum number of configured DSPs is different for each type of controller. The Advant Controller 400 Series can handle about 4000 DSPs, the Advant Controller 110 200 DSPs and Advant Controller 70 maximum 50 DSPs. The Advant Fieldbus 100 can handle about 4000 CDP’s. Each DSP uses one CDP and 50 CDP’s are reserved for each S800 I/O station configured on the bus. This means that the actual maximum number of DSPs is reduced with 50 per configured S800 I/O station. The implementations of the DSP in the Advant Controller 70/110 and the Advant Controller 400 Series do not fully correspond. Disagreements are mentioned in this chapter.

The DSP communication is managed by the DSP data base elements. Each DSP element can reference to up to eight DAT elements of the types boolean, integer, integer long and real. On the DSP data base element the number of DATs, the transmission interval, the direction of data, the identity and the station number of the sending DSP are parameters set by the users.
