TRICONEX 8300 Communication gateway card

MVME712M Transition Module

The features of the MVME712M include:

❏ Four 25-pin multiprotocol EIA-232-D serial ports (through P2 adapter) ❏ One independent printer port (through P2 adapter)

❏ Small Computer Systems Interface (SCSI) shielded connector bus interface (through P2 adapter) for connection to internal and external devices ❏ Green LED on module to indicate terminator power

❏ Yellow LED on module to indicate transceiver power ❏ SCSI terminating resistors mounted in sockets for end of cable or middle of cable configuration ❏ Modem connection on module

❏ Radio Frequency Interference (RFI) protection on front panel ❏ Electrostatic Discharge (ESD) protection on front panel

P2 Adapter Board

The MVME712M requires the use of the P2 adapter board. The features of the P2 adapter board include:

❏ A connector that permits SCSI cable connection to other SCSI devices and/or to MVME712M through a flat ribbon cable

❏ SCSI terminating resistors mounted in sockets, for end of cable or middle of cable configuration

❏ Terminator power developed on the P2 adapter from the +5 Vdc on connector P2, and fused (1 A) on the P2 adapter

❏ A connector that interfaces the EIA-232-D ports, printer port, SCSI, and Ethernet signals to the MVME712M

Specifications

The following table lists the general specifications for the MVME712M Transition Module. The subsequent sections detail cooling requirements and FCC compliance. The MVME712M routes the signals to four serial ports, implemented with four industry standard DB-25 connectors on its front panel. The serial ports may be configured for EIA-232-D DTE or DCE through jumper arrangements on the MVME712M. The MVME712M front panel also has an Ethernet port, a SCSI port, and a printer port. In addition, the MVME712M routes the EIA-232-D port 2 signals to an internal modem.

product application

Products are widely used in metallurgy, petroleum, glass, aluminum manufacturing, petrochemical industry, coal mine, papermaking, printing, textile printing and dyeing, mechanical, electronic manufacturing, automobile manufacturing, plastic machinery, electric power, water conservancy, water treatment/environmental protection, boiler heating, energy, power transmission and distribution and so on

Superior products

--ABB Accuray

--ABB Advant OCS

--ABB Advant-800xA

--ABB H&B Contrans T

--ABB H&B Freelance 2000

--Allen Bradley PLC

--GE Ran card machine accessories,PLC

--ICS Triplex Rockwell T8151B/T8461/T8310

--Triconex/Foxboro:3625/3721/3503E/FBM237/FBM242

--Emerson:CE3008/VE3008/SE3008/A6120/A6312

--Motorola:MCP750/MVME162/MVME2604/MVME5100

--Woodward:9907-164/9907-167/9905-144/9905-018

The company is mainly engaged in above brands. You are welcome to inquire from me via email!
