ABB CI861 3BSE058590R1 controller

Before delivery from the factory, the VMIVME-3122 is fully calibrated and conforms to all specifications listed in this section. Should recalibration be required, refer to the following section of this manual, and perform the indicated procedures in the order shown.

Table Notes: 1. Jumper positions are indicated as: 1,2 Shorting plug between pins 1 and 2. 2,3 Shorting plug between pins 2 and 3. REM Shorting plug removed. “Don’t care”; shorting plug can be installed or removed. 2. “SIP POS” = “Single-in-line-package position.” The indicated position is one of two possible locations for the input SIP. Only one of the two locations is occupied. For example, the SIP for channel group 00 to 03 can be located as either RP33 or RP1.

Equipment Required

Digital Voltmeter (DVM) 1.000 and 10.000 VDC ranges; 5 or more digits; ±0.003 percent of reading measurement accuracy; 10 MΩ minimum input impedance. Digital Voltage Source 10.000 VDC ±0.001 VDC voltage source; ±0.003 percent setting resolution and accuracy. 10 MΩ maximum source resistance. Chassis VMEbus backplane or equivalent, with J1 connector, 68000 Series master controller, +5 ±0.1 VDC, 7 A (reserve current) power supply. One slot allocated for testing the VMIVME-3122.

VMEbus extender board

96-pin DIN connector (2 each) i.e., DIN 96CSC WTR4093 with row A connections shorted to row B connections shorted to row C connections. This connector(s) plugs into the VMIVME-3122 P3 and P4 connectors and grounds all VMIVME-3122 inputs for calibration purposes. All channels adapter 96-pin DIN connector (2 each) i.e., DIN 96CSC WTR4093 with all row C connections shorted together and to row B and all row A connections shorted together. This connector(s) plugs into the VMIVME-3122 P3 and P4 connectors allowing input voltage to be applied to all channels simultaneously.
