TRICONEX 4609 Redundant channel module

Synchronizing Multiple VMIVME-3122s Multiple VMIVME-3122s can be synchronized together by connecting the TRIG OUT L output from P2 of a synchronizing “master” to the EXT STRT L input of all slave boards. As many as 16 boards in a single chassis can be synchronized in this manner, thereby providing up to 1,024 synchronized input channels and the simultaneous sampling of like numbered channels on all boards.

An interrupt can be generated when the data buffer is filled or half-filled, or after a specific number of A/D conversions have been completed (Operating Modes Section of this document). The interrupt response is established through the Interrupt Control and Interrupt Vector registers which are shown in ‘Software Trigger Command and Gain RAM’ Sections of this document. During VMEbus system reset operation, the Interrupt Control Register is cleared to “$FF00” and the Interrupt Vector Register is preset to “$FF00”.

Maintenance

This section provides information relative to the care and maintenance of VMIC’s products. If a product malfunctions, verify the following: • Software

• System configuration

• Electrical connections

• Jumper or configuration options

• Boards are fully inserted into their proper connector location

• Connector pins are clean and free from contamination

• No components of adjacent boards are disturbed when inserting or removing the board from the chassis • Quality of cables and I/O connections If a product must be returned, contact VMIC for a Return Material Authorization (RMA) Number. This RMA Number must be obtained prior to any retur

The VMIVME-7805/VME-7805RC

 are full featured Pentium® 4 Processor - M compatible Single Board Computers (SBCs) in a single-slot, passively cooled, Eurocard form factor that utilizes the advanced technology of Intel®’s 852GM chipset running a front-side bus rate of 400 MHz. The VMIVME-7805/ VME-7805RC are compliant with the VMEbus Specification Rev. C.1 and features a transparent PCI-to-VME bridge, allowing the board to function as a system controller or peripheral CPU in multi-CPU systems.
