ABB YB560103-CC DSQC236C Dual channel assembly module

The SS2000OF can be used wherever the speed of a step motor must be altered to match changing conditions or must be synchronized with that of another element of the system. It has been designed to meet the same construction requirements as other units of the SLO-SYN 2000 Series, and offers features that make it suited for use in a wide variety of applications.

• Compatible with all SLO-SYN step motor drives and most other pulse and direction drives

• Adjustable potentiometer controls output pulse rate, allowing variable speed control of a step motor system

• Can be controlled by a 4 to 20 milliamperes current level, a 0 to 10 volt analog signal or a -10 to +10 VDC differential voltage

SS2000I-V Closed-Loop Programmable Motion Control

The SS2000I and SS2000I-V are high performance, programmable motion controls specifically designed for use with SS2000D6 and SS2000D12 drives. They can also be used with any other SLO-SYN step motor drives as well as with most standard pulse and direction drives, including digital servo drives. The controls can be used to operate one drive, or they can operate two drives, one-at-a- time, in applications where simultaneous motion is not needed. The SS2000I is an open-loop control, which can be easily converted to closed-loop operation in the field by replacing the memory module with an optional closed-loop module. The SS2000I-V is shipped from the factory with the closed-loop module in place.

• Two axes of motion (one at a time)

• Separate acceleration and deceleration

• Velocity changes “on the fly”

• Breakpoint programming

• Choice of trapezoidal, “S” curve, or hyperbolic ramp profiles

• Mark registration accurate to ±1 microstep • Pulse outputs to 48 MHz

• Abundant, versatile, bulletproof I/O

• 16 inputs, 8 outputs

• Short-circuit proof outputs

• Built-in 24 VDC, 0.75 A power supply for I/O

• 400 lines of user program stored in BRAM
