ABB YB560103-CD DSQC236G Line interface module

ABB YB560103-CD DSQC236G Line interface module

ABB YB560103-CD DSQC236G Line interface module

The most recent addition to the SLO-SYN 2000 Series is the WARPDRIVE™ SS2000D3i/D6i series of step-motor positioning systems which provide a microstepping controller and drive in one convenient compact package. The SS2000D3i/D6i step motor positioning systems include all of the superior features of the SS2000D3/D6 drive, an integral-positioning controller with BASIC-like language programming and a power supply in one package. This versatile system will work with standard SLO-SYN step motors in size NEMA 23 to NEMA 42 and SLO-SYN High Torque Motors in sizes NEMA 23 and NEMA 34. The integral programmable controller utilizes a patent-pending digital microstepping current control technique to provide smooth motor performance.

Programming the position

controller is done via a Windows Based graphical interface and uses the same language as Superior Electric's popular versatile TDC and MX2000 controllers. In addition the New MotionWriter™, point and click graphical user interface is available for use with the SS2000D3i/D6i positioning systems.

• Packaged drive, control and power supply • 100-120V ±10% AC input

• Utilizes robust SS2000D3/D6 drive design • Motor phase current selectable up to 6 amps (D6i)

• Simplified motor selection

• Short-circuit Protection • Optically isolated I/O, 8 Inputs, 4 Outputs

• Windows based software development utility for easy programming on any PC

• Easy to use BASIC - like programming language

• Additional 8 inputs and 4 outputs, non-isolated • 16 bit microprocessor

• Encoder input for closed loop operation

(differential or single ended)

• One 0-10V analog input (10 bit resolution)

• BCD interface with separate connector

• 2 serial ports, RS232 / 485 up to 38K baud

• Built-in ac line filter and MOV's for transient protection

• Patent-pending digital microstepping current control • Smoother motor operation at low speeds

• Meets IEC 1000-4-4 standard for electrical fast transient ("noise") immunity • UL recognized and CE compliant

• Optional terminal board for easy wiring




Superior products

ABB -- AC 800M controller, Bailey, PM866 controller, IGCT silicon controlled 5SHY 3BHB01 3BHEO0 3HNA00 DSOC series

BENTLY --- 3500 system/proximitor, front and rear cards, sensors, power modules, probes, cables

Emerson -- modbus card, power panel, controller, power supply, base, power module, switchEPRO --- Data acquisition module, probe, speed sensor, vibration sensor, shaft vibration transmitter, proximitor

FOXBORO - thermal resistance input/output module, power module, communication module, cable, controller, switch

GE --- module, air switch, I/O module, display, CPU module, power module, converter, CPU board, Ethernet module, integrated protection device, power module, gas turbine card

HIMA --- DI module, processor module, AI card, pulse encoder

Honeywell --- Secure digital output card, program module, analog input card, CPU module, FIM cardMOOG - servo valve, controller, module, power module

NI --- Information acquisition card, PXI module, card, chassis multi-channel control card

WESTINGHOUSE --- RTD thermal resistance input module, AI/AO/DI/DO module, power module, control module, base module

Woodward - Regulator, module, controller, governor

YOKOGAWA - Servo module, control cabinet node unit

Obtain the latest price of ABB YB560103-CD DSQC236G Line interface module
