ABB DO802 3BSE022364R1 Digital Output Relay

ABB DO802 3BSE022364R1 Digital Output Relay

ABB DO802 3BSE022364R1 Digital Output Relay

When a UL-certification is required, then in order to prevent motor overtemperatures the servo drives may only be operated in connection with motors that are provided with an integrated motor temperature sensor. The sensor has to be connected to the servo drive and the temperature monitoring has to be activated accordingly on the software side.

Tools / material

 Screwdriver for slotted head screws size 1

 Rotary angle encoder cable

 Motor cable

 Power supply cable

 Operator panel ARS 2000 or control

 Possibly also Connector set: Power- and DSUB connector

Connecting the motor

 Plug the connector of the motor cable into the corresponding socket of the motor and screw tight  Plug PHOENIX connector into socket [X6] of the servo drive

 Connect the PE line of the motor to the PE socket

 Plug the connector of the encoder cable into the encoder output socket of the motor and screw tight

 Plug the D-Sub connector into the socket [X2A] Resolver or [X2B] Encoder of the servo drive and fasten the bolting screws

 Apply the shield of the motor or angle encoder cable over a large contact area with the aid of the shield connection clamp SK14

 Check all connections again

Connecting the servo drive ARS 2100 SE to the power supply

 Make sure that the power supply has been switched off

 Plug the PHOENIX connector into socket [X9] of the servo drive

 Connect the PE line of the mains to the PE socket

 Connect the 24 V connections to a suitable power supply unit

 Make mains supply connections

 Check all connections again



Application industry

The products can be used in the following industries: power plant, paper making, steel, mining, rubber, water supply, cement, chemical industry, glass, printing

Textile, machinery, plastics, coatings, medicine, hospitals, food, hotels, scientific research institutions
