ABB DO810-EA 3BSE008510R2 Overspeed Tachometer Module

Connecting the PC (USB interface)

 Plug the plug A of the USB interface cable into the socket for the USB interface of the PC

 Plug the plug A of the USB interface cable into the socket [X19] USB of the ARS 2100 SE servo drive

 Check all of the plug-and-socket connections once more Now, you can communicate with the servo drive via the parameterisation program Metronix ServoCommander® . For further information, please refer to the Software Manual “Servo drives ARS 2000”.

Checking operability

1Make sure the controller enabling switch is turned off 2. Switch on the power supply of all devices. The READY / ERROR LED on the front of the servo drive should now be active green If the READY LED does not light green but red, there is a malfunction. If the seven-segment display indicates a number sequence, it is displaying an error message. You have to take care of the corresponding problem. In this case please continue with chapter 11.2.2 Error messages (page 116). If the device displays nothing, follow these steps: 1. Switch off the power supply 2. Wait 5 minutes, so the DC bus can discharge 3. Check all connection cables 4. Check the functionality of the 24 V power supply 5. Switch the power supply back on

Protection and service functions

The ARS 2100 SE series servo drives have a powerful sensor analysis, which monitors the proper functioning of the controller, power output stage, motor and communication with the outside world. All occurring errors are stored in an internal error memory. Most errors will cause the controller unit to shut down the servo drive and the power output stage. They can only be switched on again after the error memory has been deleted by acknowledging the error and after the error has been eliminated or no longer exists. A powerful sensor analysis and monitoring function provides operational safety:

 Measuring of motor temperature

 Measuring of power module temperature

 Detection of ground faults (PE)

 Detection of connections between two motor phases

 Detection of overvoltage in the DC bus

 Detection of errors with the internal voltage supply

 Failure of the supply voltage.

Application industry

The products can be used in the following industries: power plant, paper making, steel, mining, rubber, water supply, cement, chemical industry, glass, printing

Textile, machinery, plastics, coatings, medicine, hospitals, food, hotels, scientific research institutions
