ABB PP320 3BSC690100R2 Display panel

DEFAULT CMOS RAM SETUP VALUES After the CMOS RAM is cleared, the system will load default CMOS RAM parameters the next time the board is powered on. The default CMOS RAM setup values will be used in order to boot the system whenever the main CMOS RAM values are blank, or when the system battery is dead or has been removed from the board.

USER DEFAULT CMOS RAM SETUP VALUES

To save CMOS Setup parameters to custom defaults, you will need a DOS bootable floppy with the Flash BIOS Update (FBU) utility on it. FBU is available from the BIOS Information page. 1. Boot the EPIC-2 and enter CMOS Setup by pressing Delete during the early boot cycle. 2. Change the CMOS parameters as desired and configure the floppy drive as the first boot device: Basic CMOS Configuration | BOOT ORDER | Boot 1st = Drive A: 3. Save the settings and exit CMOS Setup. 4. Reboot the system from the DOS boot floppy. 5. Run FBU and select Save CMOS contents. A file named CMOS.BIN is created and saved to the floppy. 6. Select the FBU option Load Custom CMOS defaults. A directory of the floppy is displayed. 7. Select the CMOS.BIN file and press the P key to program the new CMOS defaults. 8. Reboot from the hard disk. The custom CMOS parameters are now saved as defaults.

Real Time Clock

The EPIC-2 features a year 2000-compliant, battery-backed 146818-compatible real-time clock/calendar chip. Under normal battery conditions, the clock maintains accurate timekeeping functions when the board is powered off. SETTING THE CLOCK The CMOS Setup utility (accessed by pressing the [DEL] key during a system boot) can be used to set the time/date of the real-time clock.
