ABB SDCS-COM-5 3BSE006567R1 Thermal resistance module

▶ The control electronics may only be unplugged and plugged when de-energized.

▶ Only carry out measurements at the card using instruments with Ri > 100 kΩ.

▶ For switching analog command values and digital call-ups, use relays with gold-plated contacts (low voltages, low currents).

▶ Always shield command and actual value cables; connect shielding to system earth on the card-side, open at one side.

▶ Recommendation: Up to a length of 50 m, use the line type LiYCY 1.5 mm2 for solenoid line, for position transducer line use cable type LiYCY 0.5 mm2, shielded. For greater lengths, please contact us.

▶ The distance to aerial lines or radios must be at least 1 m!

▶ Do not lay solenoid conductors and signal lines near power lines.

▶ Commissioning and programming of the control electronics are described in detail in the operating instructions 30028-B.

▶ For perfect control results, the quality of the sensors is important.

GENERAL DESCRIPTION

The ADN2816 provides the receiver functions of quantization and clock and data recovery for continuous data rates from 10 Mb/s to 675 Mb/s. The ADN2816 automatically locks to all data rates without the need for an external reference clock or programming. All SONET jitter requirements are met, including jitter transfer, jitter generation, and jitter tolerance. All specifications are quoted for −40°C to +85°C ambient temperature, unless otherwise noted. The ADN2816 is available in a compact 5 mm × 5 mm 32-lead LFCSP.

FEATURES

Serial data input: 10 Mb/s to 675 Mb/s Exceeds SONET requirements for jitter transfer/ generation/tolerance Patented clock recovery architecture No reference clock required Loss-of-lock indicator I 2C® interface to access optional features Single-supply operation: 3.3 V Low power: 366 mW typical 5 mm × 5 mm 32-lead LFCSP, Pb free APPLICATIONS SONET OC-1/-3/-12 and all associated FEC rates Fibre Channel, ESCON, Fast Ethernet, SDI WDM transponders Regenerators/repeaters Test equipment Broadband crossconnects and routers
