ABB QHFT 200F YL681001-AF Front Plate

Outputs are controlled by the user’s program. To turn On an output, set the variable OUTn to 0; to turn it Off, set to 1. For example, if you set OUT6 to 0 in your program, output 6 is active (low), displayed as OUT6 = 0.Inputs 10 to 15 can be programmed for specific functions. If these inputs are not pre-defined, they act as general purpose inputs. The factory default settings for these inputs are pre-defined, but they can be used as general purpose inputs by setting PREDEF.INPn equal to 0. Functionality of the pre-defined inputs is given below Inputs 10 to 15 can be programmed for specific functions. If these inputs are not pre-defined, they act as general purpose inputs. The factory default settings for these inputs are pre-defined, but they can be used as general purpose inputs by setting PREDEF.INPn equal to 0. Functionality of the pre-defined inputs is given below

Connect discrete devices to the 6445 as follows:

1 Refer to the table and connector figure for the desired connections to your discrete devices. Select an I/O RTN for the return to ground for each device. For connection to input or output differential drivers, refer to the following sections.

2. Strip the wires to 0.27 inch (7 mm).

3. Attach the wires to the connector as indicated in the cabling diagram. Note: Make sure the screws on the PCD connector are tightened down firmly on the wiring

Encoder/Step and Direction Input Connection

Connector J11 accepts encoder quadrature inputs for A, A, B, B, Z and Z which can be used for electronic gearing, encoder position verification, and stall detection. Alternatively, a program variable can be set to switch the encoder inputs to external step and direction inputs. These converted inputs are DIR, DIR , STEP, and STEP. Encoder requirement The encoder must provide quadrature differential, line driver outputs. The receiver IC is an SM75175.To provide power for the encoder. The maximum allowable load on this pin must be an amount that, when added to the load on pins J7-4 and J10-7, totals to less than 450 mA.To provide 5 volt ground. Note: If using external power, you must connect the power supply ground here.
