The main products

Spare parts spare parts, the DCS control system of PLC system and the robot system spare parts,

Brand advantage: Allen Bradley, BentlyNevada, ABB, Emerson Ovation, Honeywell DCS, Rockwell ICS Triplex, FOXBORO, Schneider PLC, GE Fanuc, Motorola, HIMA, TRICONEX, Prosoft etc. Various kinds of imported industrial parts

SR469-P5-HI-A20 relay

Fault and Safety Detection ♦ Watchdog faults ♦ Speed and current protection (VOSPD, VLIM, ILIM) ♦ Fatal and non-fatal error coding with text explanation to the host (FLTHIST, FLTCLR). Also includes a run-time counter (TRUN) that records the time the error occurred ♦ Configurable drive thermal protection through the foldback feature (FOLD, FOLDMODE). It sets the maximum time limit the drive can provide peak current (3:1) to the motor ♦ Hardware position limit switch detection (INx, where x is 1 or 2) ♦ Configurable fault relay output (RELAY, RELAYMODE) ♦ Active enable indicator through the Status Display decimal (ACTIVE, DRIVEOK, SWEN, READY, REMOTE) General ♦ Many enabling and disabling features (K, REMOTE, EN, DIS) ♦ Flash firmware memory for easy field upgrade installation ♦ Danaher Motion Kollmorgen’s patented “Torque Angle Control” for buried magnet motor designs (MTANGLC, MTANGLP, MVANGLF, MVANGLH - defined as speed and torque optimization through commutation angle advancing of the drive’s output current waveform with respect to the motor's back EMF waveform ♦ Firmware and serial number information (VER, MOTOR) via terminal

CD-Lite versus CD

♦ Power board Logic power generated from line (SERVOSTAR CD without Top switch) ♦ Power board Logic power supplied from external 24 VDC. (Same as SERVOSTAR CD.) ♦ Digital board : Current Card Board (CCB) instead of UCB ♦ C1 – Serial Communication is RS-232 only (support for personality module) ♦ C2 – Feedback: Incremental Encoder A/B/Z/Hall, A/B/Hall, Halls only sine wave or SIX step, Resolver (only w/ Logic power supplied from external 24 VDC) ♦ C3 – Analog input, fault output, I/O, Analog output. ♦ C4 - Same as SERVOSTAR CD ♦ C7 – Not available ♦ C8 - Not available ♦ Configuration (DIP) switch settings: CD-LITE defines the RS-232 baud rate, hold switch, drive enable and disable (EN/DIS), and changes to Ember Mode ♦ MOTIONLINK (Same as SERVOSTAR CD except to Record application)

For system startup you need a PC with MOTIONLINK for windows, LE- CD-LITE drive brush less motor, and your application connected to the motor. With MOTIONLINK, you can initialize and configure you drive to your application. After that, you will connect the drive to your servo controller. You can communicate with the SERVOSTAR CD-Lite through the serial port. Since MOTIONLINK is designed to guide you through the operation process of the drive, the MOTIONLINK discussion in this section covers only general steps of use. A “dumb terminal” can also be used to communicate to the drive. You may find this method of communication very awkward until a certain level of familiarity with the drive’s operation is achieved. MOTIONLINK also provides a terminal emulation feature that contains many useful editing tools for this type of communication.
