TRICONEX 3515 Logical Sequence Card

Powered direct-on-line from a three phase supply, the SV-S range of servo drives provide an LVD compliant solution for applications requiring analogue velocity or torque control. The drives are designed for use with stand-alone single axis applications or within multiaxis applications where each axis is required to have its own independent power supply. Each drive type is self contained in its own rugged metal casing with provision for direct, flat surface, mounting.

SV2500S Drive

 The SV2500S is physically the smallest drive in the SV-S Series and uses convection cooling provided by the heatsink area forming one side of the package. When installing a number of drives side-by-side, allow 92mm between centres, giving a 2mm clearance between units. The drive is operated direct-on-line from 230V AC supplies, either single phase or three phase. Minimum input voltage is 100V AC for a single phase supply and 80V AC for a three phase supply. Provision has been made for the connection of an external ballast resistor to dissipate excessive regenerated energy during deceleration. Programming information and I/O control is common to all other SV Series drives and is fully described in later sections of this user guide.

Dimensions and Mounting Details

 The recommended mounting position is upright, as shown, with a minimum of 65mm clearance above and below the drive for good ventilation and for connector access. All dimensions are given in mm.

Common problem

We have this product in stock, and we can deliver it to you at any time when you need it badly.

*The warranty period of all products is 1 year, which has passed the professional test certification.

*If you need to order more than one product, please contact us, and we can offer you a discount.

*We only use HDL  UPS  and other express delivery methods to deliver spare parts.

*If you find that other suppliers offer lower prices for the same products, we are also willing to offer you further discounts based on their prices.

If you have any other questions, please feel free to contact us via email.

*Please let us know if you need any spare parts, we can give you further assistance, and we are waiting for your inquiry.
