ABB HENF209736R0003 DSPP4LQ DC output module

The control unit has a built-in battery-buffered SRAM for storing the tightening results. In the event of a power failure, the data in the SRAM is retained thanks to the battery. The system clock is also supplied by the battery. The above mentioned data, as well as date and time, are lost if the battery is discharged. In this case, an error message is created. Proceed as follows to exchange the battery: • Carry out data storage (when the battery is exchanged, all data stored in the memory module is lost). • Remove the discharged battery. Lift the holder slightly with a screwdriver and slide the battery forwards.

Environmental protection

Careless disposal of the SE352/SE352M control unit could lead to pollution of the environment. Therefore dispose of the device in accordance with the currently applicable regulations in your country. You can also send the device to Bosch Rexroth for disposal.Proceed as follows to disassemble the SE352/SE352M control unit: 1. Switch off the power supply to the BT356 card rack or SB35x system box and allow for a discharging time of 10 seconds. 2. Loosen the knurled screws on the front side and pull out the SE352/SE352M control unit. 3. Install a corresponding dummy panel, if necessary

Extension and conversion

 Do not convert the SE352/SE352M control unit.Malfunctions and information on errors are displayed in the tightening system via the BS350. If you are not be able to remedy an occurring defect, please contact one of the addresses that you can find under www.boschrexroth.com or in the address directory in chapter “16 Service and sales” on page 30.



Application industry

The products can be used in the following industries: power plant, paper making, steel, mining, rubber, water supply, cement, chemical industry, glass, printing

Textile, machinery, plastics, coatings, medicine, hospitals, food, hotels, scientific research institutions
