HONEYWELL 10310/2/1 Pulse output card

The pre-set operating voltage corresponds to the voltage printed on the rating plate on the side of the enclosure. The operating voltage can be optionally switched between 230 V / 115 V with the aid of a line voltage selection switch located on the main board inside the CDP-01. Always disconnect the line power lead before opening up the unit! Live components are exposed inside the processor which will endanger the life of the operator if touched.

Connecting Sensors/Actuators

• Remove power from unit or pull power plug.

• Only sensors/actuators approved by FIFE must be connected.

• The technical data of the sensor and actuator must match the connection data of the CDP-01.

• Pay attention to the installation and operating instructions of the accessories.

Checking Plug-in Connections

The unit and accessories must be properly installed and connected before startup!The main EMERGENCY OFF switch must also disconnect power to the CDP-01 processor! Start up the CDP-01 with the web at standstill. Before applying operating voltage it must be ensured that all sensors and auxiliary equipment are properly connected and all persons are kept away from the danger area of the rotating frame!
