ABB HESG447388R1 Channel isolation card

In sensor calibration the line sensor is calibrated to the color contrast. Before sensor calibration, the distance between the sensor and the material must be set so that the light spot of the line sensor is shown in sharp focus. In the following, sensor calibration is described for the respective applications. IMPORTANT Calibration is easier with the RCAL-26 control panel. RCAL-26 is one of the CDP-01 accessories.

Calibrating to Detect a Broken Print Edge

 a. Press ASC key repeatedly until LED (7) lights up or flashes. The ASC function is usually pre-set at FIFE factory for the SE-26 line sensor. However, the correct setting is again described under “SE-26" in the section on ”Setting the Sensor Proportional Band". b. Now carry out calibration as described earlier under “Calibrating to Detect a Material Edge or a Print Edge”.

Calibrating to Detect a Broken Line

a. Press ASC key repeatedly until LED (7) lights up or flashes. The ASC function is usually pre-set at FIFE factory for the SE-26 line sensor. However, the correct setting is again described under “SE-26" in the section on ”Setting the Sensor Proportional Band". b. Set Manual mode. c. Press Setup key. Check: LED (3) flashes. d. Press Sensor key repeatedly until LEDs (8 and 12) light up.
