BENTLY 125840-02 Serial Link Controller

To exit 830 Tools, click on the close window icon. You should now know how to start and exit 830 Tools, configure your drive, edit and save parameters values, and configure a drive using parameters stored in a disk file.Note: The control voltage for the PC830 controllers is input to a switching power supply. This input will accept voltages ranging from 85 to 265 Vac.

Interfaces and Connections Introduction

This chapter describes all of the connections to the PC830 and provides the information required to interface to it. In the list below an overbar on a signal name means that the signal is active low logic. For example, “Fault” indicates the drive is faulted when it is pulled low. Earth Ground Chassis Ground, M4 x 12 screw with flat and lock washer.

Chassis Ground

PE (TB1-3) Convenience connector point for the user to connect the drive’s control power and bus power to protective earth ground. This pin is directly connected to the chassis and thus to the Chassis Ground Stud. Local electrical code may require using the Earth Ground Chassis stud for this function.
