ABB DSAX 110A 3BSE018291R1 Communication module

UniOP panels must be programmed with the programming package Designer. To program a panel you will have to connect the panel to a personal computer running Designer software package; the panel must be in Configuration mode to be programmed. Use the cable CA2/CA114 to connect the panel to a personal computer. The software package Designer is a WindowsTM application and must be properly installed. The WindowsTM environment is not included in the software package Designer and must already be installed on the personal computer.

The software package

can use either the communication ports COM1 or COM2 on the personal computer. Check that the Designer program is correctly configured to comunicate with the communication port to which the cable attached. The communication parameters between the panel and the personal computer are: speed: 9600 (models PC/Printer Port support also speeds of 19200 and 38400 baud ) parity: none stop bit: 1 The Designer software defaults to the correct parameters. The version of the Designer being used must be compatible with the firmware version of the panel to be programmed. Call for more information on compatibility between firmware and programming software.

Command Summary

The chapter describes the keyboard commands recognized by UniOP panels. Commands are classified according to the operating modes of the unit. Note: The standard command assignment is described in this chapter. All the commands, except those defined for Configuration Mode, can be charged, deleted and/or extended using the Keyboard Macro Editor facility of the programming software.
