ABB PM861A Pulse output card

ABB PM861A Pulse output card

ABB PM861A Pulse output card

In the case it might be impossible to switch the operator panel to Configuration Mode due to problems in the start-up phase, follow the procedure described below: 1. Switch off the unit

2. Press and hold any 3 keys

3. Turn on the unit and hold the keys pressed until Configuration Mode will be shown on the screen.

Touchscreen Calibration

Standard calibration: 1. Recall Configuration Mode 2. Touch the CLEAR key on the screen until a small round symbol will appear on the top right corner of the screen 3. touch and hold the symbol until it will move to the low lef corner of the screen 4. touch and hold the symbol until the indication to touch the  key will be displayed on the screen 5. touch and hold the key  until the indication to touch the  key will be displayed on the screen

Emergency calibration.

The Emergency calibration procedure should be used in all cases when it would result not possible to go to calibration using the standard procedure. 1. Switch of the unit

2. turn on the unit

3. tap in the middle of the touchscreen with a frequency of about one second until the operator panel will enter the Calibration Mode 4. perform the standard calibration procedure.
