MOTOROLA MVME710B Thermal resistance module

Remove the outer covering of the cable over a length of about 30mm, without damaging the shielding braid. Press up the terminal clamp and insert the cable between the busbar and the terminal clamp. Make sure that there is a reliable contact between the clamp and the shielding braid.Insulate the back portion with heatshrink sleeving, leaving about 12mm of the braid bare. Strip off the individual cores over a length of 5mm, without damaging the stranded copper.

Crimp the contacts to the individual cores using a special crimping tool.

Put the contacts into the SubD plug, according to the wiring diagram in Chapter II.2.3 or II.2.4 (observe the core colours). Check the assignments afterwards.Attach the cable to the plug housing, using the metallic cable grip. The cable grip must seat on the bare shielding braid with a good contact. Place the knurled screw in position.When the two halves of the housing have been put together, they cannot be separated again without damage ! Place the SubD plug in the groove of the housing half (pin 1 at bottom) and close up the housing
