MOTOROLA MVME147-010A Logic conversion card

With the -IL- option you can limit the torque of the motor which is connected to the digifas™ to a freely selectable value which is less than the pulse torque, with the aid of a DC control voltage. This is achieved by changing the current setpoint by means of an external analog speed-control loop. The electronics is contained in a separate casing. Assembly : — on top-hat rails EN 50022-35 or C-rails, in the immediate vicinity of the servo amplifier Dimensions : —HxWxD (without top-hat rail) : 111 x 145 x 90 mm

Connections

 — two 8-pin Combicon connectors for control signals, setpoints and auxiliary voltages

 — SubD 9-pin socket for pulse encoder signals from digifas™

— SubD 9-pin plug to transfer the pulse encoder signals to higher-level controls Inputs :

— 2 differential amplifiers for 2 speed-setpoints ±10V = ± final speed SW1 fixed, SW2 can be decreased by P302, both SW are added

— 1 differential amplifier for current limit 0 ... 10V

— aux. supply voltage +25V DC/ 210 mA, XGND — enable via optocoupler, DGND — pulse encoder signals from digifas™ , PGND
