MOTOROLA MVME2604-1161A Vibration module

The basic style for the 6SM27..107 synchronous motors is style IM B5 according to DIN EN 60034-7. The permitted mounting positions may be read from the technical data of the motor series.The curves are based on a bearing life of 20.000 operating hours. The axial force FA must not exceed FR/3. If a brake is built-in the motor, die axial force FABR must not exceed FR/10. Double-coned collets have proved to be ideal zero-backlash coupling devices, combined, if required, with metal bellows couplings.

Shaft end, A-side

 Power transmission is made through the cylindrical shaft end A (fit k6) to DIN 748, with a locking thread (except 6SM27) but without a fitted-keyway. If the motors drive via pinions or toothed belts, then high radial forces will occur. The permissible values at the end of the shaft may be read from the diagram in chapter III.3. The maximum values at rated speed you will find at the technical data. Power take-off from the middle of the free end of the shaft allows a 10% increase in FR.



Superior products

-ABB Accuray

--ABB Advant OCS

--ABB Advant-800xA

--ABB H&B Contrans T

--ABB H&B Freelance 2000

--Allen Bradley PLC

--GE Ran card machine accessories,PLC

--ICS Triplex Rockwell T8151B/T8461/T8310

--Triconex/Foxboro:3625/3721/3503E/FBM237/FBM242

--Emerson:CE3008/VE3008/SE3008/A6120/A6312

--Motorola:MCP750/MVME162/MVME2604/MVME5100

--Woodward:9907-164/9907-167/9905-144/9905-018

The company is mainly engaged in above brands. You are welcome to inquire from me via email!
