GE DS200SLCCG3ACC Speed module

Attach the 500 ohm resistor between the pins to be measured. The current probe shall be placed around the wire between the resistor and Terminal B. Apply an ESD stress at the voltage and polarity needed to execute the qualification, re-qualification or periodic verification being conducted. Follow procedure according to socket type as described in Section 5.2.2.1.

Short Circuit Current Waveform

Attach the shorting wire between the pins to be measured. Place the current probe around the shorting wire, as close to Terminal B as practical, observing the polarity shown in Figure 1. Apply an ESD stress at the voltage and polarity needed to execute the qualification, re-qualification or periodic verification being conducted. a. For positive clamp sockets, insert the shorting wire between the socket pins connected to Terminals A and B and hold in place by closing the clamp. b. For non-positive clamp sockets, attach the shorting wire between the socket pins connected to Terminals A and B. If it is not possible to make contact within the socket, connect the shorting wire between the reference pin pair test points or socket mounting holes, if available.

Our products

A company specializes in the sales of module spare parts of global famous brands (DCS system) (robot system) (large servo control system). The company's products include distributed control system (DCS), programmable controller (PLC), MOTOROLA MVME industrial module, industrial control communication converter (Anybus), remote output/input module (RTU), industrial computer (IPC), industrial low screen screen (IPC) HMI SCSI (50, 68, 80Pin) AnyBus (Gateway) has become a global sales enterprise of industrial automation spare parts and components
