CI546 3BSE012545R1 processor module

All low-voltage signal and output cables should be regarded as communication circuits in accordance with VDE 0100 and VDE 0800 (or NEC or other equivalent). Cable Shielding • If the general guidelines for cable routing are observed, it is not necessary to shield field device signal and power supply cables. • If, for whatever reason, the routing guidelines cannot be observed, the field device signal and power supply cables must be shielded. – Shielding of cables leading to field devices must be grounded only at the cabinet end. – The shield must not be terminated at the XCL8010 Controller Module.Commissioning Panel Bus I/O Modules During CARE engineering, the HEX address of the Panel I/O modules is defined. Note In the case of Panel Bus I/O modules, it is essential that the HEX switch be set to the address assigned during CARE engineering. The XCL8010 Controller automatically commissions all Panel Bus I/O modules. Commissioning LONWORKS Bus I/O Modules Commissioning is done using CARE.The XCL8010 Controller software can be updated using CARE. Software with Panel Bus I/O Modules The XCL8010 Controller automatically updates the software of all Panel Bus I/O modules. Software with LONWORKS Bus I/O Modules The software of the LONWORKS I/O modules can be updated using CARE or EXCELON.

Connecting via LONWORKS Bus

Via a LONWORKS Bus, an Excel 800 System can be connected to other controller systems, to additional LONWORKS Bus I/O modules, or to laptops. LONWORKS Bus Termination Depending upon the configuration, either 1 or 2 termination modules are required for terminating a LONWORKS bus with FTT devices on it. The following 2 different LONWORKS termination units are available for this purpose: • 209541 LONWORKS Bus Termination Module and • XAL-Term LONWORKS Connection and Termination Module, which can be mounted on DIN rails and in fuse boxes Risk of electric shock or equipment damage! ► Do not touch any live parts in the cabinet! ► Disconnect the power supply before making connections to or removing connections from terminals of controller or I/O modules. ► Do not reconnect the power supply until you have completed installation. ► Observe the rules regarding electrostatic discharge.Via C-Bus an Excel 800 Controller can be connected to other controller systems to form a network. Connecting to the Controller ► Connect the C-Bus to the XCL8010 Controller Module as follows: – Input to C-Bus terminals 8 and 9 – Output to C-Bus terminals 5 and 6 – Do not connect the C-Bus to the cabinet earth or any other earth ground points
