GE DS200DCCAG4 Channel temperature module

With a 14-gauge wire-stripping tool, strip the three wires in the tray cable coming from the DC input power source to 8mm ± 1mm (0.31 in., ± 0.039 in.).Do not strip more than the recommended amount of wire. Stripping more than the recommended amount can create a safety hazard by leaving exposed wire on the terminal block after installation. 17 Connect the frame ground wire to the terminal marked with the ground symbol by inserting the wire into the terminal and tightening the connection with a flathead screwdriver. Warning When installing this equipment, always ensure that the frame ground connection is installed first and disconnected last. 18

Connecting the Stripped Wire

Connect the positive feed wire to the terminal block marked (+). 6. Connect the negative feed wire to the terminal block marked (-). Warning "Safety Hazard"- Check to see if there are any exposed copper strands coming from the installed wires. When this installation is done correctly there should be no exposed copper wire strands extending from the terminal block. Any exposed wiring can conduct harmful levels of electricity to persons touching the wires.
