ABB 3BHB000272R0101 Axial displacement module

The following components are supplied with the basic equipment : Micro Panel GF-1 including PC-Card retaining device and a blind plate with knurled screws for System Slot 1 • Fixing screws for device installation (4 pcs.) • Seal for device installation • Power supply plug - DC Version (GF1-xxxxD) : plug-in screw terminal (3 pole)(Poenix, Type : MSTB 2.5/3-ST-5.08) - AC Version (GF1-xxxxA) : Standard appliance plug • Device descriptio

GENERAL MOUNTING INSTRUCTIONS

The Micro Panel GF1 series comes in different mounting versions. The front panel version with 4 fixing holes (xx0) is specially designed for mounting in an enclosure or cabinet where there is no possibility of access from the rear. It is fixed from the front with four countersunk screws through the front plate (→ Section 5). The front versions with threaded bolts at the back require access from the rear. Washers and nuts are used to mount the device from the rear. All mounting versions ensure a sealed mounting to IP65. The relevant mounting instructions must be observed
