ABB 57330001-N Power AC module

With the oscilloscope function, specific signals of the drive such as

• S-0-0051, Position feedback 1 value or S-0-0053, Position feedback 2 value,

• S-0-0040, Velocity feedback value • S-0-0080, Torque/Force command

• S-0-0347, Speed deviation

• S-0-0189, Following error can be stored in 2*512-deep measurand lists.

Triggering results either from external

or thresholds that can be parametrized in the drive for position, velocity or torque data. By using the triggering stipulations, reading the measurand list and graphically illustrating the measurands stored therein by means of a parametrization interface, an oscilloscope function can be implemented. Superimposing the measuring results of axes interpolating with each other, it is possible to illustrate contour accuracy.

Company product range

----------------------Ruichang Mingsheng Automation Equipment Co., Ltd----------------------

PLC module, programmable controller, CPU module, IO module, DO module, AI module, DI module

Network communication module

Ethernet module, motion control module, analog input module, analog output module, digital input module, digital output

Module, redundancy module, power module, relay output module, relay input module, processor module

This article from the temporal Ming sheng automation equipment co., LTD., reproduced please attach this link: http://www.stockdcs.com/
