ABB 3DDE300405 Power module

1  Review the general specifications

2. Perform configuration/adjustments (if necessary)

3. Mount the ZETA6104

4. Connect all electrical system components

5. Test the installation

6. Match the motor to the ZETA6104 — optional 7. Mount the motor and couple the load 8. Optimize performance (using the ZETA6104’s damping features) — optional

Electrical Noise Guidelines

• Do not route high-voltage wires and low-level signals in the same conduit.

• Ensure that all components are properly grounded.

• Ensure that all wiring is properly shielded.

• Noise suppression guidelines for I/O cables are provided on page 19.

• Appendix D (page 49) provides guidelines on how to install the ZETA6104 in a manner most likely to minimize the ZETA6104’s emissions and to maximize the ZETA6104’s immunity to externally generated electromagnetic interference.
