GE DS215UCIBG3AZZ01A Multifunctional I/O module

Most of the software configuration commands (see table below) are not saved in non-volatile memory and therefore must be executed every time the ZETA6104 is powered up or reset. Therefore, you may wish to include the software configuration commands in the set-up program. The set-up program is automatically executed when the ZETA6104 is powered up or reset; in it, you place the configuration commands that establish the operational readiness you require for your particular application. A sample set-up program is provided below. For more detailed information on creating a set-up program, refer to the 6000 Series Programmer’s Guide.

By now, you should have completed the following tasks

 as instructed earlier in this chapter: 1. Review the general specifications — see page 3 2. Perform configuration/adjustments, as necessary — see pages 4-5 3. Mount the ZETA6104 — see page 6 4. Connect all electrical system components — see pages 7-19 Supplemental installation instructions for LVD-compliance are provided in Appendix C. 5. Test the installation — see pages 20-21 6. Match the motor to the ZETA6104 (OPTIONAL) — see pages 22-23 7. Mount the motor and couple the load — see pages 24-25 8. Optimize system performance (OPTIONAL) by implementing Active Damping and Electronic Viscosity — see pages 26-29 9. Record your system configuration information
