GE DS3800HDDA Transfer switch module

Manufacturers generally use either a unipolar rating or a bipolar rating for motor current in 8-lead motors. Unipolar Rating: If the manufacturer specifies the motor current as a unipolar rating: • Use the following formula to convert the unipolar current rating to the correct bipolar rating: Unipolar Current * 0.707 = Bipolar Current • If you wire the motor in series, use the DIP switch table’s current settings and the converted value to set the motor current. • If you wire the motor in parallel, you must double the converted value and use the DIP switch table’s current settings to set the motor current.

Bipolar Rating

If the manufacturer specifies the motor current as a bipolar series rating: • If you wire the motor in series, use the DIP switch table’s current settings directly. • If you wire the motor in parallel, you must double the manufacturer’s rating and then use the DIP switch table’s current settings to set the motor current. If you have any questions about setting motor current, consult your local Automation Technology Center (ATC) or distributor, or refer to the numbers listed under Technical Assistance on the inside front cover of this document.

Common problem

We have this product in stock, and we can deliver it to you at any time when you need it badly.

*The warranty period of all products is 1 year, which has passed the professional test certification.

*If you need to order more than one product, please contact us, and we can offer you a discount.

*We only use HDL  UPS  and other express delivery methods to deliver spare parts.

*If you find that other suppliers offer lower prices for the same products, we are also willing to offer you further discounts based on their prices.

If you have any other questions, please feel free to contact us via email.

*Please let us know if you need any spare parts, we can give you further assistance, and we are waiting for your inquiry.
