ABB 3BSC980050R46 Horizontal tension sensor

Fit the device from the front into the mounting cutout. 6 Clip on the retaining brackets in the recesses provided for them on the device as shown below and fix the device by tightening the threaded pins until the front of the MICRO PANEL is flush with the surface of the control cabinet at the fixing points.Mechanical damage to the device Tightening the threaded pins too tightly may damage the device.  Tighten threaded pins with a max. tightening torque of 0.2 Nm.

The positions of the retaining brackets depend on:

 the size of the device and  the mounting requirements.

 10.4" and 12.1" devices (standard mounting):

 Top and bottom of the device: Fit one retaining bracket each at the left and right fixing position
